NSYPLA10123G - Schneider Electric 1000x1250x320mm Floor Standing GRP Enclosure, IP65

Product Number: NSYPLA10123G

Schneider Thalassa PLA GRP - NSYPLA GRP 1000H x 1250W x 320mmD Floor Standing Enclosure with Double Plain Grey Doors; IP65; RAL7035

The Schneider Electric NSYPLA10123G is a wide-profile, shallow-depth, shorter-height floor-standing GRP (Glass Reinforced Polyester) enclosure, purpose-built for demanding industrial environments where overall height is limited but you need maximum component width. Combining a maximum 1250mm width with a shorter 1000mm height and shallow 320mm profile, this cabinet is ideal for under-workbench installations, behind-machinery layouts, low-ceiling plant rooms, and retrofit projects where standard 1250mm or 1500mm enclosures simply cannot fit.

Designed for wide access with double doors.

The 1250mm wide NSYPLA10123G features a double-door configuration with one 500mm wide door and one 750mm wide door. This asymmetric design allows you to access different sections of your equipment without exposing the entire cabinet.

The central post forms part of the robust 3-point locking system but can be temporarily removed while you work inside, giving you full, unobstructed access when fitting or maintaining components.

Key Features & Benefits:

Durable GRP Construction: Lightweight yet exceptionally strong. GRP will not corrode like steel, ensuring a long service life in harsh, humid, or chemical-laden environments.

Shorter Height (1000mm) + Maximum Width (1250mm) + Shallow Profile (320mm): The ideal combination for wide component layouts where both height and depth are limited.

High Ingress Protection: Rated IP65 – dust-tight and protected against low-pressure water jets. Suitable for washdown areas and outdoor use.

Double Asymmetric Doors (RAL7035): One 500mm and one 750mm door provide flexible access. The removable central post allows full interior access during installation.

Integrated Locking System: The 3-point locking mechanism secures both doors. The central post can be removed temporarily for easy equipment access.

Versatile Application: Perfect for housing single-layer electrical components, control systems, instrumentation, and communication equipment where height, width, and depth are all constrained.

Not Included:

An internal mounting plate is not included and must be ordered separately.

See full data sheet here
