NSYPLA10124G - Schneider Electric 1000x1250x420mm Floor Standing GRP Enclosure, IP65

Product Number: NSYPLA10124G

Schneider Thalassa PLA GRP - NSYPLA GRP 1000H x 1250W x 420mmD Floor Standing Enclosure with Double Plain Grey Doors; IP65; RAL7035

The Schneider Electric NSYPLA10124G is a wide-profile floor-standing GRP (Glass Reinforced Polyester) enclosure, purpose-built for demanding industrial environments where overall height needs to be limited but maximum component width is still required. Combining a maximum 1250mm width with a shorter 1000mm height and 420mm mid-depth profile, this cabinet is ideal for installations under mezzanines, in shipping containers, alongside conveyor systems, or anywhere vertical clearance is restricted.

With an IP65 ingress protection rating, this enclosure is completely dust-tight and water resistant.

Designed for wide access with double doors. The 1250mm wide NSYPLA10124G features a double-door configuration with one 500mm wide door and one 750mm wide door. This asymmetric design allows you to access different sections of your equipment without exposing the entire cabinet.

The central post forms part of the robust 3-point locking system but can be temporarily removed while you work inside, giving you full, unobstructed access when fitting or maintaining components. Once work is complete, the post is easily refitted to restore the original security.

Key Features & Benefits:

Durable GRP Construction: Lightweight yet exceptionally strong. GRP will not corrode like steel, ensuring a long service life in harsh, humid, or chemical-laden environments.

Shorter Height (1000mm) + Maximum Width (1250mm): The ideal combination for wide component layouts where vertical space is limited. Fits under mezzanines, in shipping containers, and alongside conveyors.

Mid-Depth 420mm Profile: Provides generous internal depth for most industrial control components without taking up excessive floor depth.

High Ingress Protection: Rated IP65 – dust-tight and water resistant. Suitable for washdown areas and outdoor use.

Double Asymmetric Doors (RAL7035): One 500mm and one 750mm door provide flexible access. The removable central post allows full interior access during installation.

Integrated Locking System: The 3-point locking mechanism secures both doors.

Versatile Application: Perfect for housing control systems, instrumentation, communication equipment, and switchgear where height is restricted.

Not Included:

An internal mounting plate is not included and must be ordered separately.

See full data sheet here
