NSYPLA12123G - Schneider Electric 1250x1250x320mm Floor Standing GRP Enclosure, IP65

Product Number: NSYPLA12123G

Schneider Electric Thalassa NSYPLA12123G | 1250H x 1250W x 320mmD GRP Floor Standing Enclosure – IP65, Double Plain Grey Doors (RAL7035)

The Schneider Electric NSYPLA12123G is a wide-profile, shallow-depth floor-standing GRP (Glass Reinforced Polyester) enclosure, purpose-built for demanding industrial environments where you need maximum component width but have limited floor depth. Combining a maximum 1250mm width with a shallow 320mm profile.

Designed for wide access with double doors. The 1250mm wide NSYPLA12123G features a double-door configuration with one 500mm wide door and one 750mm wide door. This asymmetric design allows you to access different sections of your equipment without exposing the entire cabinet.

Key Features & Benefits:

Durable GRP Construction: Lightweight yet exceptionally strong. GRP will not corrode like steel, ensuring a long service life in harsh, humid, or chemical-laden environments.

Maximum Width (1250mm) + Shallow Profile (320mm): The ideal combination for wide component layouts where floor depth is limited. Fits behind machinery, along corridors, and in retrofit spaces.

High Ingress Protection: Rated IP65 – dust-tight and protected against low-pressure water jets. Suitable for washdown areas and outdoor use.

Double Asymmetric Doors (RAL7035): One 500mm and one 750mm door provide flexible access. The removable central post allows full interior access during installation.

Integrated Locking System: The 3-point locking mechanism secures both doors. The central post can be removed temporarily for easy equipment access.

Versatile Application: Perfect for housing single-layer electrical components, control systems, instrumentation, and communication equipment where width is needed but depth is limited.

Not Included:

An internal mounting plate is not included and must be ordered separately.

See full data sheet here
