NSYPLA5104G - Schneider Electric 500x1000x420mm Floor Standing GRP Enclosure, IP65

Product Number: NSYPLA5104G

NSYPLA GRP 500H x 1000W x 420mmD Floor Standing Enclosure with Double Plain Grey Doors; IP65; RAL7035

The Schneider Electric NSYPLA5104G is a low-height, wide-profile floor-standing GRP enclosure, part of the trusted Thalassa PLA range, this 500mm high cabinet offers a compact vertical footprint combined with a generous 1000mm width and 420mm depth – perfect for operator interfaces, local control stations, and equipment that needs to be mounted at an accessible height.

With an IP65 ingress protection rating, this enclosure is completely dust-tight and water resistant.

Designed for wide access with double doors. The 1000mm wide NSYPLA5104G features a double-door configuration with two 500mm wide doors. This balanced design provides wide, symmetrical access to the entire cabinet interior.

The central post forms part of the robust 3-point locking system but can be temporarily removed while you work inside, giving you full, unobstructed access when fitting or maintaining components. Once work is complete, the post is easily refitted to restore the original security.

Key Features & Benefits:

Durable GRP Construction: Lightweight yet exceptionally strong. GRP will not corrode like steel, ensuring a long service life in harsh, humid, or chemical-laden environments.

Low Height (500mm) + Wide Width (1000mm): The ideal combination for operator-accessible control panels. Mounts controls at a comfortable working height while providing ample width for multiple components.

Mid-Depth 420mm Profile: Provides generous internal depth for most control gear, terminals, HMI components, and DIN rail layouts – typically 300-350mm usable depth behind a mounting plate.

High Ingress Protection: Rated IP65 – dust-tight and protected against low-pressure water jets. Suitable for washdown areas and outdoor use.

Double Symmetrical Doors (RAL7035): Two 500mm doors provide balanced, wide access. The removable central post allows full interior access during installation.

Integrated Locking System: The 3-point locking mechanism secures both doors.

Versatile Application: Perfect for housing HMI panels, local control stations, instrumentation, compact switchgear, and communication equipment at accessible heights.

Not Included:

An internal mounting plate is not included and must be ordered separately.

See full data sheet here
