NSYPLA7103G - Schneider Electric 750x1000x420mm Floor Standing GRP Enclosure, IP65

Product Number - NSYPLA7103G

Schneider Thalassa PLA GRP - NSYPLA GRP 750H x 1000W x 320mmD Floor Standing Enclosure with Double Plain Grey Doors; IP65; RAL7035

The Schneider Electric NSYPLA7103G is a compact-height, wide-profile floor-standing GRP enclosure, purpose-built for demanding industrial environments where you need easy access to controls at working height. Part of the trusted Thalassa PLA range, this 750mm tall enclosure is ideal for mounting at eye level, while the 1000mm width provides ample space for multiple components.

With an IP65 ingress protection rating, this enclosure is completely dust-tight and water resistant.

Designed for wide access with double doors. The 1000mm wide NSYPLA7103G features a double-door configuration with two 500mm wide doors. This balanced design provides wide access to the entire cabinet interior for installation and maintenance.

The central post forms part of the robust 3-point locking system but can be temporarily removed while you work inside, giving you full, unobstructed access when fitting or maintaining components. Once work is complete, the post is easily refitted to restore the original security.

Important depth note: Due to the shallow 320mm depth, this enclosure is not suitable for deep VSDs, large contactors, transformers, or components requiring significant rear clearance.

Key Features & Benefits:

Durable GRP Construction: Lightweight yet exceptionally strong. GRP will not corrode like steel, ensuring a long service life in harsh, humid, or chemical-laden environments.

Compact Height (750mm): Ideal for working-height installations.

Wide Profile (1000mm): Ample width for multiple components, twin 500mm doors provide balanced access.

Shallow Depth (320mm): Space-saving profile for depth-constrained plant rooms and retrofit projects.

High Ingress Protection: Rated IP65 – Dust-tight and water resistant. Suitable for outdoor use.

Double Symmetric Doors (RAL7035): Two 500mm doors provide balanced access. The removable central post allows full interior access during installation.

Integrated Locking System: The 3-point locking mechanism secures both doors.

Not Included:

An internal mounting plate is not included and must be ordered separately.

See full data sheet here
